CUTTING & CUSTOM PROJECTS Services

Yes, we can help with design and file preparation. These will be additional charges. In the form, select: I will need help completing my cutting file

File Format Requirements

• Accepted formats: DXF, DWG, AI, PDF, or SVG

• Version compatibility: DXF/DWG saved in 2014 or earlier format

• Single file submission: All cut lines in one file (avoid multiple files for one project)

Design Specifications

• Units clearly defined: Specify mm or inches in filename or notes

• Scale verification: File is drawn at 1:1 scale (actual size)

• Line weights:

  • Cut lines: 0.25mm or thinner

  • Etch/engrave lines: Clearly differentiated from cut lines

• Colour coding:

  • Engraving: Black

  • Cutting: Red

  • Tracing/scoring: Blue

• Layer organisation: Different operations on separate layers if applicable

Geometry Requirements

• Closed paths: All cut lines form complete, closed shapes

• No overlapping lines: Remove duplicate or overlapping vectors

• Minimum feature size:

  • Details ≥ 1mm for wood/plastic

  • Details ≥ 0.5mm for thin materials

• Minimum spacing: 2mm between cut lines minimum

• No tiny segments: Avoid line segments shorter than 0.1mm

Technical Considerations

• Material specification: Clearly state material type and thickness

• Quantity specified: How many pieces needed

• Kerf compensation: Indicate if kerf adjustment is required

• Grain direction: Specify for wood projects (if critical)

File Preparation

• Text converted: All text converted to outlines/curves

• Grouped objects ungrouped: Ungroup all elements

• Effects removed: No filters, effects, or bitmap elements

• Clean file: Remove construction lines, dimensions, and notes from cut file

File Format Requirements

• 2D files: DXF, DWG (for profile cutting only)

• Toolpath files: Only if specifically requested - G-code in standard format

Design Specifications

• Units clearly defined: Model created in mm or inches (specify which)

• Origin placement: Set origin at logical reference point

• Scale verification: Model is actual size (1:1 scale)

• Orientation: Part oriented for optimal machining direction

Geometry Requirements

• Minimum radius: Internal corners ≥ 1.5mm radius (3mm+ preferred)

• Draft angles: 1-2° draft on vertical walls where possible

• Feature accessibility: All features accessible with standard end mills

• Undercuts avoided: No overhanging features requiring special tooling

Technical Specifications

• Material specified: Type of wood and exact thickness

• Tolerance requirements: Critical dimensions and tolerances noted

• Surface finish: Specify required surface quality

• Quantities: Number of pieces needed

Machining Considerations

• Minimum wall thickness: ≥ 3mm for structural integrity

• Deep pocket limitations: Depth-to-width ratio considerations

• Grain orientation: Critical for strength (specify if important)

• Fixture planning: Consider how part will be held during machining

Documentation

• Assembly drawings: If multiple parts, show how they fit together

• Critical dimensions: Highlight most important measurements

• Special instructions: Note any specific requirements or concerns

• Reference edges: Indicate which edges are most critical for accuracy

Yes, we can help you source materials

We will send you an online invoice prior to starting your job, and require payment in full in advance.

We do not arrange delivery or collection. This would need to be arranged by you
